Company Info

Cangzhou Feiyang Machiney Manufacturing Co., Ltd.

Business Type:

Manufacturer
Main Products:

Roll Forming Machine , Roofing Sheet Tile Machine , C Purlin Machine , Floor Deck Machine , Sandwich Panel Production Line , Double Deck Roll Forming Machine
Export Percentage:

31% - 40%
Year Established:

2002
Main Markets:

Africa , Americas , East Europe , Middle East , North Europe

MORE Visit My Factory

Company News

Automatic roofing forming machine

2019 / 10 / 05

We have a good quality and low price automatic roof tile forming machine. Our factory serves the new and old customers with the principle of lowest price and quality. The ridge tile forming machine adopts the roller forming technology and is combined with the die hydraulic forming. The products are widely used in the roof connection of architectural color steel plates. 1. Equipment installation dimensions: 8000mm × 1300mm × 1500mm 2. Equipment weight: about 4000kg 3. Total equipment power: 7Kw 4. Hydraulic power: 4Kw 5. Pressing machine pressure wheel number: 10 channels 6. Applicable plate thickness: 0.5-0.6mm 7. Applicable board width: 500mm 8. Product length error: ± 2mm 9.Electronic control system: The whole machine adopts industrial computer PLC control, fully automatic lengthening, cutting and convenient operation. This machine can be customized according to customer's requirements.
New bamboo glazed tile equipment

2019 / 10 / 05

The new bamboo glazed tile equipment is a new type of color steel equipment control system that can also complete the single board cutting function. The glazed tile pressing machine is divided into three parts: the roller forming part, the pressing part and the cutting part. The roller forming portion is dragged by the motor, and the chain drives the rollers to rotate. The pressing part is a hydraulic cylinder that drives the mold to move up and down, and can press the color steel into many sections, which are shaped like glazed tiles. The cutter part is a hydraulic cylinder that drives the tool to move up and down, and can cut the color steel tile. The production process of the new bamboo glazed tile equipment is as follows: the colored steel plate enters the forming part of the roller table, and after molding, it is pressed into the pressing part, and is pressed into a section of equal distance, and the cutter is responsible for the fixed length cutting. The execution part has inverter drive motor, hydraulic station motor, two hydraulic solenoid valves of the pressure type, and two hydraulic solenoid valves of the cutter. The detection part includes: a pulse encoder for detecting the length of the colored steel tile, a press-type upper and lower stroke switch, a cutter upper and lower stroke switch, a press-type upper and lower operation button, a cutter upper and lower stroke button, an emergency stop switch, a hydraulic start-stop switch and many more. PLC selects KDN-K306-24AR of KDN-K3 series. It has 14 inputs / 10 relay outputs, just to meet the input and output requirements. With the KDN text screen, you can complete parameter settings, alarm display, help information, production data display, and more.
Matters needing attention when operating color steel tile press equipment

2019 / 08 / 09

1 Pay attention to safety when the equipment is live. 2 Do not put your hands or foreign objects into the knife at any time. 3 The electrical cabinet should be protected from rain and sun; the counter should prevent hard objects from colliding; the line should be prevented from being broken by the board. 4 The machine is often lubricated with the moving parts. 5 Power off when plugging and unplugging the aviation plug
